Hymenoptera
>
Ichneumonoidea
>
Ichneumonidae
>
Ctenopelmatinae
>
Key to Northern European Ctenopelmatinae
Steps
Steps
Taxa:
Body color
chevron_right
Body predominantly testaceus.
Body not predominantly testaceus.
Flagellum
chevron_right
Flagellum with a white band centrally.
Flagellum without white band.
Glymma
chevron_right
1. Glymmae deep and ending in a translucent membrane either in the middle where both glymmae connect or in the basal depression.
2. Glymmae present but not ending in a translucent membrane.
3. Glymmae absent.
Areolet
chevron_right
Areolet present.
Areolet absent.
Occipital carina
chevron_right
1. Occipital carina complete.
2. Occipital carina interupted medially. Vertex and occipit without impression.
3. Occipital carina interupted medially by a deep impression on the vertex and occipit.
Nervellus
chevron_right
1. Nervellus intercepted above the middle.
2. Nervellus intercepted around the middle.
3. Nervellus intercepted below the middle or not intercepted.
Thyridia
chevron_right
Thyridia present.
Thyridia absent.
Mandible
chevron_right
1. Mandible with upper tooth longer or clearly broader than the lower.
2. Madible with both teeth about equal in size.
3. Mandible with lower tooth longer or clearly broader than the upper.
Clypeus
chevron_right
1. Lower margin of clypeus with a distinct denticle.
2. Lower margin of clypeus sharp medially.
3. Lower margin of clypeus at least narrowly blunt medially, or if somewhat sharp then the margin is overlapped by a blunt buldge.
Eyes
chevron_right
1. Eyes bare and very strongly converging ventrally.
2. Eyes sparsely hairy and weakly converging ventrally.
3. Eyes bare and not or weakly converging ventrally.
Frons
chevron_right
Frons with a strong median longitudinal carina. Face broad. Female with metasoma very long and narrow.
Frons without strong median longitudinal carina.
Tergite 8
chevron_right
Sides of tergite 8 of female strongly produced backward between base of ovipositor sheaths and cerci so that they touch in the middle.
Sides of tergite 8 of female not or weakly produced backward between base of ovipositor sheaths and cerci.
Tergite 2 carina
chevron_right
Each side of tergite 2 with a carina running between the base and the spiracle.
Tergite 2 without carinae between base and the spiracles.
Claws
chevron_right
Claws distinctly pectinate.
Claws apparently simple.
Dorso-lateral carinae
chevron_right
Dorso-lateral carinae reaching apex of tergite 1.
Dorso-lateral carinae not reaching apex of tergite 1.
Dorsal carinae
chevron_right
Dorsal carinae of tergite 1 reaching level of the spiracles, usually distinct.
Dorsal carinae of tergite 1 not reaching level of the spiracles, often absent or very weak.
Propodeal carination
chevron_right
Propodeal carination complete or almost complete, median and lateral longitudinal carinae distinct.
Propodeal carination reduced, either median or lateral longitudinal carinae absent or very short.
Trochanters
chevron_right
Hind trochantellus flat or concave ventrally and with a strong transverse ridge.
Hind trochantellus rounded ventrally and without transverse ridge.
Ovipositor shape
chevron_right
1. Ovipositor with a more or less distinct dorsal notch and relatively short.
2. Ovipositor slender, completely without notch and relatively short.
3. Ovipositor about as long as the metasoma.
Ovipositor curvature
chevron_right
Ovipositor (and usually ovipositor sheaths) upcurved.
Ovipositor straight or downcurved.
Ovipositor sheath shape
chevron_right
Ovipositor sheaths broad, sometimes almost circular or triangular.
Ovipositor sheaths relatively narrow.
Tergites
chevron_right
2nd and usually 1s tergite with a broad transverse impression.
Suture between 2nd and 3rd tergite rigid so that they are immovably joined. Tergite 2 often with a pair of central warts.
Tergites without transverse impressions. 2nd and 3rd tergite not fused and tergite 2 without central warts.
Discosubmarginal cell
chevron_right
Discosubmarginal cell with a brown sclerotized spot.
Discosubmarginal cell without sclerotized spot.
Mesopleuron
chevron_right
Mesopleuron with a distinct longitudinal furrow between the epicnemial carina and hind margin.
Mesopleuron without longitudinal between the epicnemial carina and hind margin.
Vein AA
chevron_right
Vein AA with a triangular thickening.
Vein AA without a triangular thickening.
Occipital / hypostomal carina
chevron_right
Occipital carina joinging hypostomal carina at the base of the mandible.
Occipital carina joining hypostomal carina above the base of the mandible.
Epicnemial carina
chevron_right
Epicnemial carina reaching the anterion margin of the mesopleuron.
Epicnemial carina at least narrowly removed from the anterior margin of the mesopleuron.
Ovipositor sheath direction
chevron_right
Ovipositor sheaths pointed directly backwards or slightly downwards.
Ovipositor sheaths more or less pointed upwards.
Parameres
chevron_right
Apex of each paramere with a elongate lobe.
Apex of parameres without elongate lobes.
Median apical area
chevron_right
Propodeum with the median apical area enclosed by carinae.
Propodeum without an enclosed median apical area.
Mandible depression
chevron_right
Mandible with a transverse basal depression.
Mandible without a transverse basal depression.
Occeli
chevron_right
Ocelli of female very large, lateral ocellus separated from the eye by about 0.2 of its diameter.
Ocelli of female smaller, lateral ocellus separated from the eye by more than 0.2 of its diameter.
Clypeus width
chevron_right
Clypeus very short and wide, about 3.5 times wider than long.
Clyeus longer, less than 3.5 times wider than long.
Face
chevron_right
Face densely covered by downwards-pointed white hairs.
Face not densely covered by downwards-pointed white hairs.
Metanotum / propodeum
chevron_right
Metanotum separated from the longitudinal carina of the propodeum by a u-shaped notch.
Metanotum not separated from the longitudinal carina of the propodeum by a u-shaped notch.
First flagellar segment
chevron_right
First flagellar segment very short, shorter than second segments.
First flagellar segment at least as long as the second segment.
Spurs
chevron_right
Length of longest spur of hind tibia / length of 5th segment of hind tarsus =
Wing length
chevron_right
Length of fore wing (mm) =
Tergite 1
chevron_right
Length of tergite 1 / width of tergite 1 =
Tergite 2
chevron_right
Tergite 2 about as wide as long.
Tergite 2 at least 1.3 times as long as wide.
Parameres / aedeagus
chevron_right
Each paramere with with a single, large, spine-like seta ventrally on the inner apical margin.
Aedeagus reflexed and pointed apically and ending in an adze-like blade.
Parameres without spine-like setae. Adeagus not as in option 2.
Alexeter group / Campodorus group
chevron_right
Usually more slender species. Dorsal carinae of tergite 1 absent or very weak and short. Clypeus often with a rounded transverse ridge.
Usually more robust species. Dorsal carinae of tergite 1 nearly always distinct, though sometimes only represented by a pair of faint but relatively long ridges. Clypeus usually without rounded transverse ridge.
Campodorus group
chevron_right
Metasoma in females less elongate, portion behind tergite 3 shorter than hind femur. Clypeus margin blunt and usually buldging centrally. Nervellus usually inclivous. Coloration of metasoma variable. tergite 2 often less than 1.7 times as wide as long.
Metasoma in females more elongate, portion behind tergite 3 about as long as hind femur. Clypeus margin blunt and usually buldging centrally. Nervellus usually inclivous. Metasoma black, without red areas and often with white hind margins on the tergites.
Metasoma variable in females. Clypeus usually bilobed and with margin sharp medially. Nervellus more or less vertical. Coloration of metasoma variable.
Metasoma relatively short in females. Clypeus margin blunt and usually buldging centrally. tergite 2 1.7 - 2.3 times as wide as long.
Synomelix / Pantorhaestes / Zemiophora
chevron_right
Hind tibia without distinct black basal band, though sometimes somewhat darkened basally. Petiolar carina extending at least over half the propodeum.
Hind tibia without distinct black basal band, though sometimes somewhat darkened basally. Petiolar area extending over less than half the propodeum.
Hind tibia ivory with a distinct black band basally and apically.
Oetophorus / Perilissus
chevron_right
Females with thin lateral lobes along the ventral margin of the clypeus. Nervellus subvertical. Metasoma black and usually with the ventral magins of the apical tergites white.
Females without lateral lobes along the ventral margin of the clypeus. Nervellus subvertical to reclivous. Metasoma often partially or entierly red and rarely with white markings.
Anisotacrus / Hadrodactylus
chevron_right
Apical tarsal segments almost always at least slightly elongate and curved. Clypeus moderately short, its apical margin moderatly to strongly curved. Metasoma usually very elongate, the 1st segment often longer than the combined length of the hid coxa and trochanter.
Apical tarsal segments normal. Clypeus very short and wide, its margin subtruncate or weakly cruved. Metasoma usually not as elongate, the 1st segment not longer than the combined length of the hid coxa and trochanter.
Alexeter / Neostroblia / Scopesis
chevron_right
Clypeus relatively broad. Setae on the hypopygium slanted backwards. Notauli strong, sharply impressed at least anteriorly. tergite 1 1.7 to 4 times as long as wide. Usually slender species with very variable coloration.
Clypeus relatively narrow. Setae on the hypopygium erect. Notauli weak, short and not sharpy impressed. Relatively robust species with black mesosoma/metasoma except of the often red mesoscutum and red central tergites. 2 northern species.
Clypeus relatively broad. Setae on the hypopygium slanted backwards. Notauli usually weak, if sharply impressed then only anteriorly. 1st tergite 1.5 to 2.3 times as long as wide. Usually slender species with variable coloration.
Cuboscopesis / Scopesis
chevron_right
Spurs of hind tibia almost equally sized and short. Temples long and large. Ocelli small. Clypeus swollen and coarsely punctate or rugose. Mesopleuron coarsely rugose or rugose-punctate.
Spurs of hind tibia usually longer and of distinctly unequal. At least partially different.
Alochera / Otlophorus
chevron_right
Dorsal carina seldom distinct as far back as the spiracles. One northern european speices.
Dorsal carina reaches spiracles. About 11 northern european species species.
Hypamblys / Phobetes / Synodites
chevron_right
Lower margin of clypeus at least sharp laterally.
Lower margin of clypeus blunt throughout its entire length. Petiolar area of propodeum completely defined.
Lower margin of clypeus blunt throughout its entire length. Petiolar area of propodeum not defined dorsally.
Mesopleuron sculpture
chevron_right
Mesopleuron entirely coarsely sculptured, wrinkled to rugulose-mat, except for the speculum.
Mesopleuron matt to polished, not coarsely sculptured.
Clypeus sculpture
chevron_right
Clypeus relatively flat, broad, and sparsely punctate.
Cylpeus usually convex, often narrower, and usually with denser punctuation or sculpture.
Alexeter / Barytarbes / Lagarotis
chevron_right
Notauli usually rather long and sharp, usually reaching front edge of mesoscutum. First tergite long and narrow. Mandibular teeth equal or almost so.
Notauli short, weak, or absent. First tergite wider and shorter. Lower mandibular tooth clearly longer than the upper tooth. Propodeum without carinae, except sometimes short apical stubs of the median dorsal carinae. Mesopleuron mat.
Notauli short, weak, or absent. First tergite wider and shorter. Lower mandibular tooth clearly longer than the upper tooth. Propodeum with more or less distinct carinae. Mesopleuron polished, mat or coarsely sculptured, wrinkled to rugulose-mat.
Hind tarsi
chevron_right
Fifth segment of hind tarsi much more elongate and curved than the previous segments.
Fifth segment of hind tarsi not particularly elongate or curved.
Face color (female)
chevron_right
ignore!
Remaining taxa:
Absyrtus
Alexeter
Alochera
Anisotacrus
Anoncus
Arbelus sanguinipes
Asthenara
Azelus erythropalpus
Barytarbes
Campodorus
Ctenopelma
Cuboscopesis fraterna
Dentimachus politus
Euryproctus
Glyptorhaestus
Gunomeria
Hadrodactylus
Himerta
Hodostates
Homaspis
Hypamblys
Hyperbatus
Hypsantyx lituratorius
Labrossyta scotoptera
Lagarotis
Lamachus
Lathiponus semiluctuosus
Lathrolestes (part)
Lathrolestes verticalis
Lethades (part)
Lethades amauronemati
Lophyroplectus oblongopunctatus
Mesoleius
Mesoleptidea
Neostroblia
Notopygus
Occapes selandriae
Oetophorus naevius
Olethrodotis modesta
Opheltes glaucopterus
Otlophorus
Pantorhaestes xanthostomus
Perilissus
Perispuda
Phaestus
Phobetes
Phobetes nigriceps
Pion
Priopoda
Protarchus
Rhaestus
Rhinotorus
Rhorus
Saotis
Scolobates
Scopesis
Seleucus cuneiformis
Semimesoleius exophthalmicus
Smicrolius parvicalcar
Sympherta
Syndipnus
Synodites
Synoecetes
Synomelix
Syntactus
Trematopygodes aprilinus
Trematopygus
Xenoschesis
Zaplethocornia
Zemiophora
Discarded taxa:
Info
This key covers the genera of Ctenopelmatinae known to occur in northern Europe. It is mainly based on the descriptions provided by Bob Wharton at
The Wharton Lab
, though Townes (1970) functions as the backbone. It is worth noting that Wharton's descriptions are not perfect. He often focuses on the Nearctic fauna and sometimes underestimate the variation within genera. I've improved the data with personal observations where possible, but further work is needed until it is completely satisfactory.
The presence or absence of a closed areolet is heavily relied upon, much like in all existing keys. This is, unfortunately, an unreliable character since aberrant specimens occur with partially or completely closed areolet in species where it should be open, and vice versa. Check both wings, and preferably multiple specimens to minimize the risk of errors.
If you find any errors, please contact me. Illustrations will be added eventually.
References
Finlands Artdatacenter (2024). LAJI.FI: Ctenopelmatinae.
https://laji.fi/en/taxon/MX.309379
[2024-11-12]
Kasparyan D. R., & Khalaim A. I. (2007). 14. Subfamily Ctenopelmatinae. In Ler, P. A. (Ed.),
Key to the insects of Russian Far East. Vol. IV. Neuropteroidea, Mecoptera, Hymenoptera. Pt 5
(s. 474–559). Vladivostok.
Ridedel, M., Florez, A. H., & Schmidt, S. (2024). Revision of the Palaearctic species of
Scopesis
FÖRSTER (Hymenoptera, Ichneumonidae, Ctenopelmatinae).
Linzer biologische Beiträge, 56
(1), 201–252.
SLU Artdatabanken (2024). Artfakta: Ctenopelmatinae.
https://artfakta.se/taxa/1000044
[2024-11-12]
Townes, H. K. (1970). The genera of Ichneumonidae, Part 3.
Memoirs of the American Entomological Institute, 13
, 1–307.
Wharton, B. (2024). PEET Ctenopelmatinae.
The Wharton Lab
.
http://mx.speciesfile.org/projects/8/public/otu_group/show/194
